A biplot simultaneously displays information on the observations (as points) and the variables (as vectors) in a multidimensional dataset. The 2D biplot is typically based on the first two principal components of a dataset, giving a rank 2 approximation to the data. The “bi” in biplot refers to the fact that two sets of points (i.e., the rows and columns of the data matrix) are visualized by scalar products, not the fact that the display is usually two-dimensional.

The biplot method for principal component analysis was originally defined by Gabriel (1971, 1981). Gower & Hand (1996) give a more complete treatment. Greenacre (2010) is a practical user-oriented guide to biplots. Gower et al. (2011) is the most up to date exposition of biplot methodology.

This implementation handles the results of a principal components analysis using prcomp, princomp, PCA and dudi.pca; also handles a discriminant analysis using lda.

Usage

ggbiplot(
  pcobj,
  choices = 1:2,
  scale = 1,
  pc.biplot = TRUE,
  obs.scale = 1 - scale,
  var.scale = scale,
  var.factor = 1,
  groups = NULL,
  point.size = 1.5,
  ellipse = FALSE,
  ellipse.prob = 0.68,
  ellipse.linewidth = 1.3,
  ellipse.fill = TRUE,
  ellipse.alpha = 0.25,
  labels = NULL,
  labels.size = 3,
  alpha = 1,
  var.axes = TRUE,
  circle = FALSE,
  circle.prob = 0.68,
  varname.size = 3,
  varname.adjust = 1.25,
  varname.color = "black",
  varname.abbrev = FALSE,
  axis.title = "PC",
  ...
)

Arguments

pcobj

an object returned by prcomp, princomp, PCA, dudi.pca, or lda

choices

Which components to plot? An integer vector of length 2.

scale

Covariance biplot (scale = 1), form biplot (scale = 0). When scale = 1 (the default), the inner product between the variables approximates the covariance and the distance between the points approximates the Mahalanobis distance.

pc.biplot

Logical, for compatibility with biplot.princomp(). If TRUE, use what Gabriel (1971) refers to as a "principal component biplot", with \(\alpha = 1\) and observations scaled up by \(sqrt(n)\) and variables scaled down by \(sqrt(n)\). Then inner products between variables approximate covariances and distances between observations approximate Mahalanobis distance.

obs.scale

Scale factor to apply to observations

var.scale

Scale factor to apply to variables

var.factor

Factor to be applied to variable vectors after scaling. This allows the variable vectors to be reflected (var.factor = -1) or expanded in length (var.factor > 1) for greater visibility. reflect provides a simpler way to reflect the variables.

groups

Optional factor variable indicating the groups that the observations belong to. If provided the points will be colored according to groups and this allows data ellipses also to be drawn when ellipse = TRUE.

point.size

Size of observation points.

ellipse

Logical; draw a normal data ellipse for each group?

ellipse.prob

Coverage size of the data ellipse in Normal probability

ellipse.linewidth

Thickness of the line outlining the ellipses

ellipse.fill

Logical; should the ellipses be filled?

ellipse.alpha

Transparency value (0 - 1) for filled ellipses

labels

Optional vector of labels for the observations. Often, this will be specified as the row.names() of the dataset.

labels.size

Size of the text used for the point labels

alpha

Alpha transparency value for the points (0 = transparent, 1 = opaque)

var.axes

logical; draw arrows for the variables?

circle

draw a correlation circle? (only applies when prcomp was called with scale = TRUE and when var.scale = 1)

circle.prob

Size of the correlation circle

varname.size

Size of the text for variable names

varname.adjust

Adjustment factor the placement of the variable names, >= 1 means farther from the arrow

varname.color

Color for the variable vectors and names

varname.abbrev

logical; whether or not to abbreviate the variable names, using abbreviate.

axis.title

character; the prefix used as the axis labels. Default: "PC".

...

other arguments passed down

Value

a ggplot2 plot object of class c("gg", "ggplot")

Details

The biplot is constructed by using the singular value decomposition (SVD) to obtain a low-rank approximation to the data matrix \(\mathbf{X}_{n \times p}\) (centered, and optionally scaled to unit variances) whose \(n\) rows are the observations and whose \(p\) columns are the variables.

Using the SVD, the matrix \(\mathbf{X}\), of rank \(r \le p\) can be expressed exactly as $$\mathbf{X} = \mathbf{U} \mathbf{\Lambda} \mathbf{V}' = \Sigma_i^r \lambda_i \mathbf{u}_i \mathbf{v}_i' \; ,$$

where

  • \(\mathbf{U}\) is an \(n \times r\) orthonormal matrix of observation scores; these are also the eigenvectors of \(\mathbf{X} \mathbf{X}'\),

  • \(\mathbf{\Lambda}\) is an \(r \times r\) diagonal matrix of singular values, \(\lambda_1 \ge \lambda_2 \ge \cdots \lambda_r\)

  • \(\mathbf{V}\) is an \(r \times p\) orthonormal matrix of variable weights and also the eigenvectors of \(\mathbf{X}' \mathbf{X}\).

Then, a rank 2 (or 3) PCA approximation \(\widehat{\mathbf{X}}\) to the data matrix used in the biplot can be obtained from the first 2 (or 3) singular values \(\lambda_i\) and the corresponding \(\mathbf{u}_i, \mathbf{v}_i\) as

$$\mathbf{X} \approx \widehat{\mathbf{X}} = \lambda_1 \mathbf{u}_1 \mathbf{v}_1' + \lambda_2 \mathbf{u}_2 \mathbf{v}_2' \; .$$

The variance of \(\mathbf{X}\) accounted for by each term is \(\lambda_i^2\).

The biplot is then obtained by overlaying two scatterplots that share a common set of axes and have a between-set scalar product interpretation. Typically, the observations (rows of \(\mathbf{X}\)) are represented as points and the variables (columns of \(\mathbf{X}\)) are represented as vectors from the origin.

The scale factor, \(\alpha\) allows the variances of the components to be apportioned between the row points and column vectors, with different interpretations, by representing the approximation \(\widehat{\mathbf{X}}\) as the product of two matrices,

$$\widehat{\mathbf{X}} = (\mathbf{U} \mathbf{\Lambda}^\alpha) (\mathbf{\Lambda}^{1-\alpha} \mathbf{V}')$$

The choice \(\alpha = 1\), assigning the singular values totally to the left factor, gives a distance interpretation to the row display and \(\alpha = 0\) gives a distance interpretation to the column display. \(\alpha = 1/2\) gives a symmetrically scaled biplot.

When the singular values are assigned totally to the left or to the right factor, the resultant coordinates are called principal coordinates and the sum of squared coordinates on each dimension equal the corresponding singular value. The other matrix, to which no part of the singular values is assigned, contains the so-called standard coordinates and have sum of squared values equal to 1.0.

References

Gabriel, K. R. (1971). The biplot graphical display of matrices with application to principal component analysis. Biometrika, 58, 453–467. doi:10.2307/2334381 .

Gabriel, K. R. (1981). Biplot display of multivariate matrices for inspection of data and diagnosis. In V. Barnett (Ed.), Interpreting Multivariate Data. London: Wiley.

Greenacre, M. (2010). Biplots in Practice. BBVA Foundation, Bilbao, Spain. Available for free at https://www.fbbva.es/microsite/multivariate-statistics/.

J.C. Gower and D. J. Hand (1996). Biplots. Chapman & Hall.

Gower, J. C., Lubbe, S. G., & Roux, N. J. L. (2011). Understanding Biplots. Wiley.

See also

reflect, ggscreeplot; biplot for the original stats package version; fviz_pca_biplot for the factoextra package version.

Author

Vincent Q. Vu.

Examples

data(wine)
library(ggplot2)
wine.pca <- prcomp(wine, scale. = TRUE)
ggbiplot(wine.pca,
         obs.scale = 1, var.scale = 1,
         varname.size = 4,
         groups = wine.class,
         ellipse = TRUE, circle = TRUE)


data(iris)
iris.pca <- prcomp (~ Sepal.Length + Sepal.Width + Petal.Length + Petal.Width,
                    data=iris,
                    scale. = TRUE)
ggbiplot(iris.pca, obs.scale = 1, var.scale = 1,
         groups = iris$Species, point.size=2,
         varname.size = 5,
         varname.color = "black",
         varname.adjust = 1.2,
         ellipse = TRUE,
         circle = TRUE) +
  labs(fill = "Species", color = "Species") +
  theme_minimal(base_size = 14) +
  theme(legend.direction = 'horizontal', legend.position = 'top')
