Diagonal Panel Function for Pairs Plots of Contingency Tables

Source: R/pairs_diagonal_mosaic.R
pairs_diagonal_mosaic.Rd

An enhanced replacement for pairs_diagonal_mosaic from the vcd package. This version fixes two bugs in the original (the labeling and alternate_labels arguments were hardcoded and ignored) and changes the default labeling to labeling_border.

Usage

pairs_diagonal_mosaic(
  split_vertical = TRUE,
  margins = unit(0, "lines"),
  offset_labels = -0.4,
  offset_varnames = 0,
  gp = NULL,
  fill = "grey",
  labeling = labeling_border,
  alternate_labels = TRUE,
  ...
)

# S3 method for class 'table'
pairs(x, diag_panel = pairs_diagonal_mosaic, ...)

Arguments

split_vertical

Logical; passed to mosaic. Default is TRUE.

margins

A unit object giving the margins around the mosaic. Default is unit(0, "lines").

offset_labels

Numeric; offset for the cell labels. Default is -0.4.

offset_varnames

Numeric; offset for the variable name labels. Default is 0.

gp

A gpar object for the mosaic tiles, or NULL (default) to use fill.

fill

Either a color name or a function mapping an integer to a vector of colors (e.g. a shading function). Default is "grey".

labeling

A labeling function such as labeling_border or labeling_values. Default is labeling_border (no cell counts shown).

alternate_labels

Logical; whether to alternate label positions on the axes. Default is TRUE.

...

Additional arguments passed to the vcd pairs.table method.

x

A contingency table (object of class "table").

diag_panel

A "grapcon_generator" function or a panel function for the diagonal cells. Defaults to the vcdExtra version of pairs_diagonal_mosaic.

Value

A function of class "grapcon_generator" suitable for use as the diag_panel argument in pairs.table.

Details

A companion pairs.table method is also provided that uses this improved function as the default diagonal panel.

The function follows the "grapcon_generator" pattern used throughout vcd: calling pairs_diagonal_mosaic(...) returns a function suitable for passing as the diag_panel argument of pairs.table.

The original vcd::pairs_diagonal_mosaic has two bugs: (1) the labeling argument is accepted but then hardcoded to labeling_values inside the returned function, and (2) alternate_labels is similarly hardcoded to TRUE. This version fixes both, making those arguments work as documented.

The default labeling scheme was changed from labeling_values to labeling_border, so as to disable cell counts by default. To enable cell counts, use labeling_values.

pairs.table is an S3 method for pairs that overrides the version in vcd solely to change the default diag_panel to the improved pairs_diagonal_mosaic defined in this package. All actual rendering is delegated to the vcd implementation, retrieved via utils::getFromNamespace() to avoid a ::: check NOTE.

See also

pairs.table, pairs_diagonal_mosaic, labeling_border, labeling_values

Examples

data(Hoyt, package = "vcdExtra")
pred_tab <- margin.table(Hoyt, c("Rank", "Occupation", "Sex"))

# Default: no cell counts in diagonal panels
pairs(pred_tab)


# Show cell counts in diagonal panels
pairs(pred_tab, diag_panel_args = list(labeling = labeling_values))


# Use residual shading for off-diagonal panels
pairs(pred_tab, gp = shading_Friendly)
